Should I Still Use Zabbix In AWS?

by Leave a Comment

Should I Still Use Zabbix In AWS

Should I Still Use Zabbix In AWS?

Amazon EC2 monitoring

Zabbix has a high market share as an integrated OSS monitoring tool.  Although it has been widely used in on-premise environments, there are many examples of Zabbix being used in AWS environments.  In spite of the fact that AWS also has monitoring services such as Amazon CloudWatch, why should you use Zabbix?  This section explains the benefits of monitoring EC2 instances and other instances, as well as the configuration process.

Why use Zabbix instead of Amazon CloudWatch?

In an AWS environment, all of the infrastructure is operated by AWS, but you must be responsible for the operation of the Amazon EC2 instances themselves and the applications built on Amazon EC2. In other words, you must monitor the applications to ensure that they are operating properly, and you must take action when a problem occurs.  Zabbix is a good candidate for this kind of monitoring tool.

Zabbix has the advantage of being able to monitor not only on-premises. But also cloud and virtual environments in an integrated manner.

Whereas the standard Amazon CloudWatch is limited to monitoring AWS resources (CPU, memory, etc.), Zabbix allows you to monitor even the state of your applications in detail.

The following is a list of other advantages of Zabbix.

Integrated monitoring of environments with multiple AWS accounts

Amazon CloudWatch performs monitoring on a per AWS account basis.  Zabbix can monitor an environment of multiple AWS accounts, that can be monitoring business systems consisting of multiple accounts.  It can also detect anomalies not only by simple alerts based on thresholds, but also by multiple thresholds and conditions in combination.

It can be configured with detailed notifications to suit the actual conditions of operation

Amazon CloudWatch can notify you with a message in the event of an anomaly.  For example, if your system is down for maintenance, you don’t need to be notified by message.  This is where Zabbix allows you to configure these cases in a way that allows you to suppress unwanted messages.  This way you can ensure that you are only notified when something is really wrong that needs to be addressed.

No retention period for metrics (monitoring log)

With Amazon CloudWatch, metrics can be stored for up to 15 months.  Moreover, you can only store metrics in hourly increments for 15 months, and if the monitoring interval is set to less than 60 seconds, you can only store them for a maximum of 3 hours.  Zabbix allows for long-term storage of metrics without changing the granularity of information.

How to monitor AWS environment with Zabbix

If you want to use Zabbix in an AWS, you will need to create an Amazon EC2 and DB instance and install Zabbix on it.  After installation, the process of configuring Zabbix is basically the same as on-premise, except that you will need to set up the following

  1. User account (in addition to the Admin user of Zabbix, you will need to create a user for production use)
  2. Zabbix host agent (determines where the data is collected from)
  3. Items (setting what data to collect)
  4. Triggers (defining what state the data is in that is abnormal)
  5. Actions (defining the actions to be taken when an error occurs)

In addition, you can configure AWS-specific settings, such as creating a user in AWS IAM with the necessary permissions for Zabbix, which will allow Zabbix to monitor applications and other aspects of your AWS environment.

Use the right tool for your monitoring needs

Not all corporate systems operate in isolation, but many systems are linked together to exchange data and ensure consistency as a whole.  In these environments, Zabbix is a great tool for monitoring and detecting anomalies across multiple servers and systems.  For example, if a DB-based web application has an anomaly on the web application server, it is possible to disable the data, for example.

On the other hand, Zabbix has a lot of configuration options, so you will have to decide what to monitor and how, and what conditions are abnormal.

On the other hand, Zabbix has a lot of settings, so you have to design the operation exactly what to monitor and what to do about it, and what to do about it. Of course, for critical systems such a design is essential, however, for relatively simple systems, such as “if a process stops, just restart it”, there is no match for Zabbix monitoring.  SIOS AppKeeper is a good solution for such cases, as it monitors services (processes) of an application running on an EC2 instance, and restarts the application if it detects the issues. This enables simple monitoring and operation.

 Of course, it is not “mandatory” to use Zabbix on every system.  By using the right tool for each type of monitoring, you will be able to operate your system more efficiently.

Add  SIOS AppKeeper to your EC2 monitoring and recovery operations.

Reproduced from SIOS

How To Choose A Cloud When You Need High Availability

by Leave a Comment

How to Choose a Cloud when you need High Availability

How To Choose A Cloud When You Need High Availability

Understand the cloud market

A number of analyst firms are predicting an ever-increasing number of deployments of applications, databases, and solutions in the cloud. According to Gartner, firms are “moving to the cloud at an increasing rate.”[1] In fact, Gartner and other analysts expect the pace of cloud migration and deployment will continue to accelerate, driven in large part by the pace of innovation in the cloud. In a TechTarget article by Kurt Marko, of MarkoInsights, Marko notes that the pace of innovation that is “being undertaken in the cloud likely can’t be replicated on premises due to the elastic, scalable, and on-demand nature of managed public cloud services.”

We see more and more companies that had been using the cloud only for DevOps applications and databases that were not essential to their business, are now moving mission-critical applications, ERPs and databases that require high availability protection to the cloud.

If you are considering a move to the cloud – and it seems likely that you are – there are several keys to understand when you need high availability.

Familiarize yourself with the cloud high availability options

To plan for the proper availability solution for a cloud or hybrid cloud deployment, consider what the pain points are with regards to both availability (99.9% uptime) and high availability (99.99% uptime). You also need to understand the options that are available for high availability with an eye towards your plans to migrate to the cloud. Notable analysts and experts suggest looking for solutions that will not only mitigate and reduce the pain of migrating your workloads, but will also provide a balanced and comprehensive approach to availability throughout the lifespan of your cloud architecture. Note, it is also wise to consider solutions that can provide protection and high availability for portions of your workload that may one day repatriate from the cloud back to your on-premises environment.

Here are ten things to consider when comparing your availability options in the cloud:

1. The deployment method. Is it possible to deploy the availability solution you are considering  using an image, CLI, UI, or other repeatable solution such as cloud formation template or packaged scripts.

2. The system requirements. Most notably, consider the operating system (OS), disk, CPU, and memory requirements.

3. The deployment environments. Do your availability options support on-premises only, one or more public clouds, or can they support a mixture, and/or hybrid cloud deployment. Is there a SaaS offering available as well?

4. The breadth and depth of application protection. “Breadth” meaning what types of applications, databases, front-ends, networking, and infrastructure components can be protected?  Is there a flexible framework for adding new applications and variants? “Depth” meaning – is the solution application-aware – and able to maintain application-specific best practices throughout the application failover/failback processes?

5. Performance requirements. We often think of RTO and RPO, but what about other performance needs of your solution. Will your availability solution cause performance issues on failover?

6. Resilience requirements. How large a cluster can the availability solution support?, How many faults and failures can it detect and recover from. How will replication be handled while keeping metadata in sync?

7. Supportability and maintenance. Does the availability vendor have experience with a wide range of availability needs and configurations? Do they have longevity, and a support system designed to address issues that may go beyond their solution? Can they help you minimize disruption and planned downtime during your system management and maintenance (patches, upgrades, and general maintenance).

8. Total cost of ownership. There are entire industries and services dedicated to helping you calculate the total cost of ownership, so we won’t cover that here. Suffice it to say, your calculations will be unique to your organization, cloud provider, applications, and IT team. You should consider whether your availability solution vendor can help you identify strategies for saving utilization, licensing, and other costs? Does the solution automate manual tasks, reduce IT labor time?

9. Licensing and pricing model. How do you consume the cost of the software? Is there a subscription fee, subscription model, pay-as-you-go offering, bring your own license (BYOL), or combination of flexible options. How will you enable the product licensing?  Is there a license server, licensing service, or encrypted key based on virtual machine deployment details, such as address, hostname, MAC address.

10. The impact on IT staff. How much training with the solution require? How much manual intervention will be needed in the event of an application failure event or disaster? Will it require specialized scripting that needs to be maintained? Who will be responsible for ongoing maintenance?

Weigh the benefits and trade-offs

Like every important decision, you need to understand your tradeoffs and choose the best balance to meet your needs. For example, I recently asked a friend to recommend a good walking shoe. I bought a pair he raved about – noting how lightweight they were, how strong and durable the fabric, and how stylish they were.  I went for my first long walk-run in them, and I donated my first pair of “one run” shoes immediately thereafter. When I went to ‘Fleet Feet’ to get an expert’s opinion I ended up with a heavier shoe, with more breathable fabric (also less durable), and an unrivaled level of hideousness. I made a tradeoff between appearance and function that worked for my needs and budget.

Like running shoes, there is no silver bullet solution that will be the right fit for every company, every application, every database, and every possible server and architecture. You are officially free to stop looking for it. Instead, settle into the activity of weighing the trade-offs to determine what is the right fit for your company’s needs. Think about your tradeoffs. For example, if you’re sure you will be a full Microsoft shop, the importance of GCP and AWS support should be a little lower in your evaluation process.

Take your IT infrastructure dynamics into account

Think holistically about availability in your entire IT infrastructure – both on premises and in the cloud. The reasons to do so are best explained with another analogy. In 2018, I was the coordinator for an outreach program feeding the homeless and hungry in Columbia, South Carolina. Our group met once a week to serve a meal and a message of hope to over 100 men, women and children. When we considered expanding – adding more days of the week, more hours, or additional services, we had to think well beyond simple scheduling requirements. Knowing that we were providing a critical service to clients who depend on us, we had to consider all the factors that affected our ability to deliver those services consistently for the long-term, such as: cost, ages of our team members, outside obligations, alternative methods to achieve our goals, risk factors, and other dynamics within our parent organization.

When you are choosing your solution, after you’ve understood the market, familiarized yourself with options, and weighed the trade-offs, the last step is to take into account the various other dynamics in your overall environment. Will the solution meet the needs of your business as a whole? Will your critical data be protected from loss? Will your end-user productivity be protected from downtime? What training will be required to move to the cloud and how will that impact your ability to manage or maintain the solution that you choose? What IT roles will be added, removed, or changed in your cloud journey?  Will any responsibilities for application availability move to any line-of-business owners? And how will the shifts in responsibilities, or team make up improve or decrease your overall potential for success. Consider whether your team needs to take a step-by-step approach, migrating smaller workloads first.

As VP of Customer Experience, I have seen a wide range of cloud migrating planning – some straightforward others extremely disruptive. In one instance a customers’ move to the cloud was highly contentious because management saw it as an opportunity to eliminate an entire IT department. I’m not suggesting that you play politics, but you should be aware of all of the factors at play in these complex projects.

Migrating to the cloud is supposed to save money, time and resources while affording improvements in availability and resilience. Regardless of which cloud you choose, make sure that you consider these tips and select the corresponding availability solution that gives you the flexibility to deliver the protection you need in the configuration you want.

Learn more about cloud high availability options with SIOS.

– Cassius Rhue, VP of Customer Experience, SIOS

Reproduced with permission from SIOS

Calculating Application Availability In The Cloud

by Leave a Comment

Calculating Application Availability In The Cloud

Calculating Application Availability In The Cloud

When deploying business critical applications in the cloud, you want to make sure they are highly available. The good news is that if you plan properly, you can achieve 99.99% (4-nines) of availability or more. However, calculating your true availability may not be as straightforward as it seems.

When considering availability, you must consider the key components that make access to your application possible, which I’ll call the availability chain. Component of the availability chain are:

  • Compute
  • Network
  • Storage
  • Application
  • Dependent services

Your application is only as available as your weakest link, and your downtime increases exponentially with each additional link you add to the chain.  Let’s examine each of the links.

Compute Availability

Each of the three major cloud service providers have some similarities. One thing in common across all three platforms is the service level agreements (SLA) they will commit to for compute.

The SLA for all three public cloud providers for VMs when you have two or more VMs configured across different availability zones is 99.99%. Keep in mind, this SLA only guarantees the remote accessibility of one of the VMs at any given time, it makes no promises as to the availability of the services or application(s) running inside the VM. If you deploy a single VM within a single datacenter, this SLA varies from “90% of each hour” (AWS) to 99.5% (Azure and GCP) or 99.9% (Azure single VM when using Premium SSD).

True high availability starts at 99.99%, so the first step is to ensure your application is available is to make sure the application is distributed across two or more VMs that span availability zones. With two VMs spread across two availability zones, giving you 99.99% availability of at least one of those VMs, you could theorize that if you had three VMs spread across three availability zones your availability would be even greater than 99.99%. Although the cloud providers’ SLA will never guarantee beyond 99.99% availability regardless of the number of availability zones in use, if you use pure statistics you might come to the conclusion that your availability could jump to as high as 99.999999% or 8-nines of availability, 26.30 milliseconds downtime per month.

1-(.0001*.0001) = .99999999

99.999999% availability with three availability zones?

Don’t go around quoting that number. But just keep in mind that it makes sense that if two availability zones can give you 99.99% availability. It stands to reason that three availability zones is going to give you something significantly more than 99.99% availability.

Compute is just one link in the availability chain. We still have to address network, storage and other dependent services, which all represent possible points of failure.

Network Availability

In order for your application to be available, every network hop between the client and the application and all the resources that the application depends on, must be available and working within tolerable latency ranges. You need to understand the network links between database servers, application servers, web servers and clients to know precisely where the network might fail. Remember, the more links in your availability chain the lower your overall availability will be.

Although network availability betweens VMs in the same vNet are covered under the standard compute SLA, there are other network services that you may be utilizing. Here are just a few examples of network services you could be utilizing which would impact overall application availability.

Express Route – 99.95%
VPN Gateway – 99.9% through 99.95%
Load Balancer – 99.99%
Traffic Manager – 99.99%
Elastic Load Balancer – 99.99%
Direct Connect – 99.9% – 99.99%

Building on what we have learned so far, let’s take a look at the availability of an application that is deployed across two availability zones.

99.99% compute availability

99.99% load balancer availability

.9999 * .9999 = .9998

99.98% availability = ~9 minutes downtime per month

Now that we have addressed compute and network availability, let’s move on to storage.

Storage Availability

Now here is where the story gets a little hairy. Have a look at the following storage SLAs

https://azure.microsoft.com/en-us/support/legal/sla/storage/v1_5/

https://cloud.google.com/storage/sla

https://aws.amazon.com/compute/sla/

It seems pretty clear that Azure and Google are giving you a 99.9% SLA on block storage solutions. AWS doesn’t mention EBS specifically here. They only talk about VMs and measure their single instance VMs availability by the hour instead of by the month as the other cloud providers do. For sake of discussion, lets use the 99.9% availability guarantee that both Azure and GCP have published.

Building upon our previous example, let’s add some storage to the equation.

99.99% compute availability

99.99% load balancer availability

99.9% managed disk

.9999 * .9999 * .999 = .9988

99.88% availability = ~53 minutes of downtime per month.

53 minutes of downtime is a lot more than the 9 minutes of downtime we calculated in our previous example. What can we do to minimize the impact of the 99.9% storage availability? We have to build more redundancy in the storage!

Fortunately, we usually include storage redundancy when planning for application availability. For instance, when we stand up web servers, each web server will typically store data on the locally attached disk. When deploying domain controllers, Microsoft Active Directory takes care of replicating AD information across all the domain controllers. In the case of something like SQL Server, we leverage things Always On Availability Groups or SIOS DataKeeper to keep the data in sync across locally attached disks.

The more copies of the data we have distributed across different availability zones, the more likely we will be able to survive a failure.

For example, an application that stores its data across two different disks in different availability zones will benefit from the redundancy and instead of 99.9% availability it is more likely to achieve 99.9999% availability of the storage.

1 – (.001 * .001) = .999999

If we throw that into the previous equation, the picture starts to look a little brighter.

.9999 * .9999 * .999999 = .9998

99.98% availability = ~9 minutes of downtime

By duplicating the data across multiple AZs, and therefore multiple disks, we have effectively mitigated the downtime associated with cloud storage.

Application And Dependent Services Availability

You’ve done all you can do to ensure compute, network, and storage availability. But what about the application itself? Some applications can scale out and provide redundancy by load balancing between multiple instances of the same application. Think of your typical web server farm where you may typically load balance web requests between five servers. If you lose one server, the load balancer simply removes it from its rotation until it is once again responsive.

Other applications require a little more care and monitoring. Take SQL Server for instance. Typically Always On Availability Groups or Failover Cluster Instances are used to monitor database availability and take recovery actions should a database become unresponsive due to application or system level failures. While there is no published SLA for SQL Server availability solutions, it is commonly accepted that when configured properly for high availability, a SQL Server can provide 99.99% availability.

You may rely on other cloud based services, like hosted Active Directory, hosted DNS, microservices, or even the availability of the cloud portal itself should all be factored into your overall availability equation.

Summary

Application availability is the sum of all the moving parts. Skimping in just one area can exponentially impact the overall availability of your application. Take your time and investigate all the links in your availability chain for weakness including compute, network, storage, application and dependent services.

In general the numbers presented here are hopefully worst case scenarios and your actual availability should exceed the published SLAs. Do your homework and be wary of any service that can not guarantee 99.99% availability, the typical threshold of what is considered highly available.

Human error and security were not addressed in this article. You can make your application as highly available as possible. However, if you have not taken steps to secure your application against external threats and stupid human mistakes then all bets are off when it comes to availability.

5 Signs That It Will Take More Than A Blog Post To Fix Your High Availability

by Leave a Comment

5 signs that it will take more than a blog post to fix your high availability

5 Signs That It Will Take More Than A Blog Post To Fix Your High Availability

The signs are there. The warning lights are flashing.  In your gut, you can sense it. Maybe you can’t sleep.  Your problems with high availability are deep. But, maybe you are not quite sure.

1. If you think your cloud SLA is all you need for high availability

Cloud solutions have provided great advancements in increased hardware availability and resilience. However, application high availability requires more than just selecting the right hypervisor or cloud provider. Your strategy for high availability cannot stop with the SLA provided by the cloud or a virtualization provider. As quoted by Wired, “The almost four-day Amazon outage of April 2011 did not breach Amazon’s EC2 SLA, which as a FAQ explains, “guarantees 99.95% availability of the service within a Region over a trailing 365 period.” In this DZone article, our own David Bermingham breaks down the differences between cloud SLAs and application availability in detail. If you want a highly available infrastructure, it must include monitoring, recovery, and resilience at the data and application layers as well.

2. If you are just using the high availability clustering that came with your open source operating system

If so, then chances are you didn’t select your database based on what was bundled with the OS, so why would you select your HA solution based on that criteria alone. Bundled tools go a long way in providing extra assurance, possibilities, and capabilities. However, despite the ease of access, bundled tools and OS clustering software are not always capable of meeting your SLA, RPO, RTO, and availability requirements. If your enterprise has a combination of Operating Systems, your team will likely need help navigating different tools and understanding how they integrate together. It’s kind of like choosing the hedge clippers and push reel mower left on the curb to shape “Azalea” on the 13th hole par 5 (at Augusta). Both lawn mowers are designed to cut grass but how much time do you have? How are you going to handle the complexity? Which would you trust? Your strategy for high availability requires more than just considering the conveniences of what is bundled with the OS, otherwise, you’d be running MySQL instead of SAP HANA.

3. If you think that enterprise application licensing, such as SQL Enterprise or Oracle Enterprise, is the same thing as enterprise high availability

In addition to increased cost, many enterprise application licenses also increase the ability of the application to recover in some high availability scenarios. However, it is highly unlikely that your entire enterprise is based on a single application. Your high availability is going to require more than just a highly available database solution. You’ll need an enterprise grade application monitoring and recovery solution with a breadth of support for all of your applications and databases. In addition, you’ll need the ability to manage and replicate not just database data, but critical application and configuration data as well. Availability for a single database or a simple application is one thing – but HA for a complex, multipart application and supporting database is very different. More services, more parts that need to be coordinated, more complex architecture to orchestrate, more specific best practices to adhere to before, during and after failover/switchover. More than what your enterprise license paid for.

4. If your downtime is growing and your uptime is shrinking

The pace of life is ever increasing in many fields. When was the last time your team recovered from backup, manually restarted the applications that were deemed critical, or restarted a set of failed virtual machines or nodes? The pace of your outage events cannot continue to outpace sustainability, or your team’s ability to move beyond firefighting to fire prevention and fire proofing. “You can only run so hard so long (Carey Nieuwhof).” For some of you, you’ve been firefighting for too long, and your outages are becoming more common than your up-time.

5. If your first failover test was on the production server

A recent client remarked that it is simply impossible to test for every possible disaster scenario. As new software is created, deployed, updated, and patched the challenges in higher availability are increasing. But, your live, production data is not the place to find out what does not play well together. And while Go-Live and Post-Go-Live will always have their share of surprises, the inability to actually failover and run on the backup node should not be one of them.

Scouring blogs can provide you with helpful tips and insights to define, redefine, and improve your higher availability. But, if the warning signs are going off that you’ve traded true availability for some semblance of ‘just enough’, then it will take more than a blog post, or scouring every blog post in the availability world for that matter, to fix your HA.

– Cassius Rhue, Vice President, Customer Experience

Reproduced with permission from SIOS

9 Signs You Have an Application Availability Problem

by Leave a Comment

9 Signs You Have an Application Availability Problem

You’ve heard the saying “recognizing a problem is the first step in solving it.”  But, many small, medium, and surprisingly, even large enterprise businesses aren’t aware that their application availability isn’t what it should be.

Read on for these nine signs that you still have an application availability problem:

1. You spend more time restarting an application than using it

Application crashes may be a fact of life, but if your application is down more often than it is up, that is a problem.

2. You’ve started to snooze through the alert storm in your inbox or control center

You have deployed alerts for application or server downtime, but the alert storm has so overwhelmed your inbox that you have silenced them all.

3. You have one data center for all your critical operations

A single data center for operations may sound convenient, but one well intended but misdirected construction crew has been known to turn single data centers into costly unavailability zones.

4. Your idea of data protection involves backup retrieval and archives

Your data protection strategy is critical. Data replication technology and site to site, region to region replication has become a mainstay, so if your replication or data protection strategy is non-existent or involves a lengthy jog to the vault this could be a big problem.

5. Your recovery procedures always require manual intervention

Manual intervention itself is not a problem. Some events are so difficult and complex that some amount of manual effort could be required.  But, if manual intervention is always the first, second and third order of business after a server or application outage, that is a problem.

6. Your RTO is measured in days not hours or minutes

How are you measuring your recovery time objective (RTO)? Do you measure your RTO in days or hours instead of minutes per month?  True, every business has a tolerance level for their RTO.  However, your RTO should not be a function of server rebuilds and gross instabilities in your architecture.

7. You don’t know your RPO because your standby is never reliably in sync

You’ve checked the box on reliable monitoring and recovery of your application, and taken it a step further to provide a standby cluster ready system.  Great job.  But, before I let you off the hook, what is your recovery point objective (RPO)? An RPO should be something more accurate than “somewhere between day 0 and last night.”

8. Single points of failure don’t just exist, they are the norm

Where are your single points of failure?  Your budget may not allow you to eliminate every single point of failure, but if you can identify a single point of failure in every major category and every critical component of your enterprise…

9. Your last disaster made local, regional, or national news

If the last major storm, grid failure, or failure event put a blight on your business due to downtime, then higher availability is the next order of business.

Downtime costs your business in terms of customers, productivity, and peace of mind.  Unaddressed risks have a definite impact on your business and reputation.  If these warning signings are there, you may have an availability problem.  And, if you ignore them you’ll likely have even bigger problems soon thereafter, hence the importance of application availability.

— Cassius Rhue, VP, Customer Experience

Reproduced with permission from SIOS
